Clamp Fitting Sizing Guide

Clamp Fitting Sizing Guide Clamp Fitting Sizing Guide Clamp Fitting Sizing Guide Clamp Fitting Sizing Guide Clamp Fitting Sizing Guide

PRODUCT CATALOG

Clamp Fitting Sizing Guide Catalog

PRODUCT SPECIFICATIONS

Clamp Fitting Size Guide

Alloy: T304 or T316L

Sizes: 1/2" OD  --  3" OD





Clamp Fitting Sizing Guide

We, at Sanitary Solutions, are pleased to supply the following clamp fitting sizing guide so you can check your clamp fitting to make sure that the size is accurate. Keep this guide handy when you are traveling to the plant and checking inventory bins for eyeing a fitting, valve or process line that is not marked.

Upon downloading the Clamp Fitting Sizing Guide on Page 164 in our "NEW 2015 SANITARY SOLUTIONS CATALOG", please take a few moments to put your fitting to the size and verify that it is the size that you need.

As you can see, the Outside Diameter of the clamp end of the 1/2" and 3/4' size is the same but the Inside Diameter of each size varies. This same principle holds true for the 1.00" and 1.50" sizes also. Please be aware!

It is our hope when you download this clamp fitting sizing guide that you can utilize this tool to assist you, your sales personnel and distribution/warehouse team when making a correct decision on the size of a clamp fitting.

This clamp fitting sizing guide is designed to take the guesswork out of the size that you think it is by just placing it up against the black area that matches the correct size, so you know the correct size of the clamp fitting instead of making an educated guess.

Please be sure and download a copy for yourself so you can take the guesswork out of the size that you are eyeing.

If you have any question, please feel free to contact our sales team at Sanitary Solutions-- 1-888-909-3569 or 1-855-640-7871.



Ordering Specifications-- Quantity-- Part Number-- Size -- Alloy--
